Sanyo PLC-XU4000 Service Manual

-45-
Electrical Adjustments
Group/
Item
Item Name Function Initial Range Note
17 DIMMER_LEVEL_AUTO Current Dimmer Leverl - 0 - 128 * Read only
18 DIMMER_LEVEL_NORMAL Normal Dimmer Level 128 0 - 128
19 DIMMER_LEVEL_ECO Eco Dimmer Level 95 0 - 128
20 Lamp check enable 0 0 - 1
0: Lamp Failure Detection OFF
(White 50% Back), 1 : ON (Blue
100% Back)
21 VOLTAGE_LEVEL Lamp Voltage - Unit: 8bit(Raw Data) * Read only
22 DIMMER_LEVEL_HIGH Dimmer level High 71 0 - 128
Group
230
VBI Slice Level
0 Generic Initial Slicing Level PW190 register 0xE344 9 0-255
1 Generic High Level Threshold PW190 register 0xE345 0 0-255
2 Generic Low Level Threshold PW190 register 0xE346 0 0-255
3 Generic Minimum Low Level PW190 register 0xE347 0 0-255
4 Generic Maximum High Level PW190 register 0xE348 255 0-255
Group
250
FAN Control
0 FAN1 MIN ADJUST (DAC)
DAC Output for Fan
Adjust the tolerance of DAC and Fan
Volage.
* Lamp mode is forced Eco
18 0-255
1 FAN1 MAX ADJUST (DAC) 207 0-255
2 FAN2 MIN ADJUST (DAC) 45 0-255
3 FAN2 MAX ADJUST (DAC) 207 0-255
4 FAN3 MIN ADJUST (DAC) 34 0-255
5 FAN3 MAX ADJUST (DAC) 194 0-255
Group
252
FAN Option
0 HI-LAND SWITCH
0: Normal, 1: Hi-Land, 2-4: Hi-Land
1-3
0 0 - 5
1 SAFETY SWITCH For test purpose 0 0 - 6
2 FAN MANUAL SWITCH 0: Auto, 1: Manual 0 0 - 3
3 FAN1 MANUAL VOLTAGE
Fan Voltage (unit : 0.1V)
Effective only when Fan Manual
switch is 1
100 0-255
4 FAN2 MANUAL VOLTAGE 100 0-255
5 FAN3 MANUAL VOLTAGE 100 0-255
Group
253
Fan Tem Error Setting (Memorized) Normal Ceiling
HiLand-
Normal
ON1/
ON2
HiLand-
Ceiling
ON1/
ON2
0 Temp A Warning (High) 9999 -
1 Temp B Warning (High) 9999 -
2 Temp C Warning (High) 9999 -
3 Temp B-A Warning(High) 9999 -
4 Temp C-A Warning(High) 9999 -
5 Temp A Warning (Normal)
Temp. A to judge the Temp Error at
Normal (Room)
38 38 35/35 35/35 30-100
6 Temp B Warning (Normal)
Temp. B to judge the Temp Error at
Normal (Panel)
52 52 51/52 51/52 30-100
7 Temp C Warning (Normal)
Temp. C to judge the Temp Error at
Normal (Lamp)
67 66 64/65 64/65 30-100
8 Temp B-A Warning (Normal)
Temp. B-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100/100 100/100 0-100
9 Temp C-A Warning(Normal)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100/100 100/100 0-100
10 Temp A Warning (Eco)
Temp. A to judge the Temp Error at Eco
(Room)
38 38 35/35 35/35 30-100
11 Temp B Warning (Eco)
Temp. B to judge the Temp Error at
Eco(Panel)
52 52 50/52 50/52 30-100
12 Temp C Warning (Eco)
Temp. C to judge the Temp Error at
Eco(Panel)
58 58 55/58 55/58 30-100
13 Temp B-A Warning (Eco)
Temp. B-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100/100 100/100 0-100
