Sanyo PLC-XU4000 Service Manual

-46-
Electrical Adjustments
Gro u p/
Item
Item Name Function Initial Range
Note
14 Temp C-A Warning (Eco)
Temp. C-A to judge the Temp Error at
Normal (Clogging Det.)
100 100 100/100 100/100 0-100
15
Temp A Warning Offset
(Temp)
Offset of Temp Error (Temp.)
Error Setting Value is increased XC at
the below condition
* Standby
* Right to turn on the lamp
* Right to change the Lamp mode
5 0-100
16
Temp B Warning Offset
(Temp)
5 0-100
17
Temp C Warning Offset
(Temp)
10 0-100
18
Temp B-A Warning Offset
(Temp)
0 0-100
19
Temp C-A Warning Offset
(Temp)
0 0-100
20
Temp A Warning Offset
(Time)
Offset of Temp Error (Minutes)
Error Setting Value is increased X
minute at the below condition
* Standby
* Right to turn on the lamp
* Right to change the Lamp mode
3 0-5
21
Temp B Warning Offset
(Time)
3 0-5
22
Temp C Warning Offset
(Time)
3 0-5
23
Temp B-A Warning Offset
(Time)
3 0-5
24
Temp C-A Warning Offset
(Time)
3 0-5
Group
254
Fan Control Range Setting (Temp./Voltage) Normal Ceiling
HiLand-
Normal
ON1/ON2
HiLand-Ceiling
ON1/ON2
0 High Fan Control Min Temp 9999 -
1 High Fan Control Max Temp 9999 -
2 High Fan1 Min 9999 -
3 High Fan1 Max 9999 -
4 High Fan2 Min 9999 -
5 High Fan2 Max 9999 -
6 High Fan3 Min 9999 -
7 High Fan3 Max 9999 -
10
Normal Fan Control Min
Temp
Temp Sensor Control Start/End Temp
at Normal
28 27 27/27 27/26 20-100
11
Normal Fan Control Max
Temp
36 35 32/32 32/32 20-100
12 Normal Fan1 Min
Fan voltage value at Normal (unit: 0.1V)
65 65 78/90 78/90 0-255
13 Normal Fan1 Max 130 130 135/135 135/135 0-255
14 Normal Fan2 Min 67 70 85/100 85/100 0-255
15 Normal Fan2 Max 120 120 130/135 130/135 0-255
16 Normal Fan3 Min 70 70 90/105 90/105 0-255
17 Normal Fan3 Max 75 75 95/112 95/115 0-255
20 Eco Fan Control Min Temp
Temp Sensor Control Start/End Temp
at Eco
28 28 26/26 26/26 20-100
21 Eco Fan Control Max Temp 35 35 32/32 32/32 20-100
22 Eco Fan1 Min
Fan voltage value at Eco (unit: 0.1V)
50 50 67/67 67/67 0-255
23 Eco Fan1 Max 120 120 125/130 125/130 0-255
24 Eco Fan2 Min 55 57 67/85 67/85 0-255
25 Eco Fan2 Max 100 100 110/120 110/120 0-255
26 Eco Fan3 Min 35 35 47/55 47/55 0-255
27 Eco Fan3 Max 38 38 52/60 52/60 0-255
Group
255
Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage(0.1V)
60 0-255
1 Fan2 Initial Volt 60 0-255
2 Fan3 Initial Volt 50 0-255
4 Fan1 Cooling Speed
Fan Voltage at Power Off (0.1V)
135 0-255
5 Fan2 Cooling Speed 135 0-255
6 Fan3 Cooling Speed 135 0-255
8 Cooling Time L1
Cooling Time setting at Fan Mode L1
(x 30 sec) 1: 30, 3: 90, 15: 450 sec.
2 1-15
9 Cooling Time L2
Cooling Time setting at Fan Mode L2
(x 30 sec)
1: 30, 3: 90, 15: 450 sec.
3 1-15
10 Temp Error Cooling Time
Cooling Time setting at Temp Erro (x
30 sec)
3 1-15
