Key No. Part No. Description Key No. Part No. Description
Electrical Parts List
-78-
KA2-XU400000
ASSEMBLED BOARDS
! A600 655 004 1418 ASSY,PWB,POWER KZ8AC
! A630 655 004 1401 ASSY,PWB,FILTER KZ8AC
! A1000 655 004 1470 ASSY,PWB,MAIN KA2AC
! A1001 655 004 1463 ASSY,PWB,AV KA2AC
! A1002 655 004 1456 ASSY,PWB,RC KA2AC
! A1003 655 004 1449 ASSY,PWB,ID CONNECT KA2AC
! A2200 655 004 3313 ASSY,PWB,SUB POWER KA2AC
OUT OF CIRCUIT BOARD
L601 945 033 2228 CORE,FERRITE
952 001 9431 CORE,CLAMP
! A901 645 103 7121 UNIT,BALLAST
A901A 610 345 4276 CABLE,BALLAST KR5AC
! LP900 610 352 7949 COMPL OPTICAL LAMP-KA2AC
! FN901 645 103 9774 MOTOR,BLW DC 2.4W
! FN902 645 103 9774 MOTOR,BLW DC 2.4W
! FN903 645 103 9774 MOTOR,BLW DC 2.4W
! FN904 645 104 1098 MOTOR,FAN DC 2.52W
! FN905 645 104 1104 MOTOR,FAN DC 2.52W
! FN906 645 104 1081 MOTOR,BLW DC 2.04W
K10B1 312 073 0406 SPECIAL SCREW
K10B2 312 073 0406 SPECIAL SCREW
K10C1 312 073 0406 SPECIAL SCREW
K10C2 312 073 0406 SPECIAL SCREW
K20A1 312 073 0406 SPECIAL SCREW
K20A2 312 073 0406 SPECIAL SCREW
SP901 652 003 2699 SPEAKER,8
SW901 645 097 3925 SWITCH,MICRO 1P-2T
! Z6B&6C(SW902)
652 003 3672 ASSY,WIRE
A600 655 004 1418 ASSY,PWB,POWER KZ8AC
TRANSISTOR
Q611 305 217 6600 TR 2SK3934
Q612 305 217 6600 TR 2SK3934
Q621 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q622 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 405 223 4406 TR 2S4085LS
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q661 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
C611 303 222 1316 CERAMIC 1000P K 1K
C612 303 222 1316 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 125 6501 ELECT 220U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1108 CERAMIC 1000P K 50V
C626 303 396 9613 CERAMIC 1U K 25V
403 478 5912 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V
C629 303 265 3216 CERAMIC 1000P J 50V
C631 303 157 4215 CERAMIC 220P J 50V
C632 303 245 4417 CERAMIC 470P K 2K
C633 303 265 3216 CERAMIC 1000P J 50V
C634 304 091 3309 CERAMIC 2200P K 50V
C641 304 091 2609 CERAMIC 0.1U K 50V
C644 303 417 9912 CERAMIC 4.7U K 25V
C651 304 108 0901 ELECT 220U M 25V
C653 303 370 1510 CERAMIC 0.1U K 50V
C661 403 468 6219 ELECT 1500U M 25V
C662 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C663 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C664 303 429 6718 ELECT 1500U M 10V
C665 303 409 9913 ELECT 470U M 16V
C666 303 392 0733 ELECT 1000U M 25V
C671 304 091 2609 CERAMIC 0.1U K 50V
C674 403 477 6514 MT-POLYEST 0.01U J 630V
C691 304 104 9502 CERAMIC 1500P M 250V
C692 304 104 9502 CERAMIC 1500P M 250V
! C693 304 073 4508 CERAMIC 2200P M 250V
RESISTOR
R611 401 353 0311 MT-GLAZE 430K JA 1/3W
R612 401 353 0212 MT-GLAZE 360K JA 1/3W
R613 301 256 6314 MT-GLAZE 47K JA 1/10W
R614 302 106 5508 RESISTER 0.075 KB 5W
R615 402 122 0409 MT-GLAZE 680K DD 1/4W
R616 402 122 0409 MT-GLAZE 680K DD 1/4W
R617 301 256 6314 MT-GLAZE 47K JA 1/10W
R618 401 361 2314 MT-GLAZE 750K JA 1/3W
To Next Page
