Key No. Part No. Description Key No. Part No. Description
-79-
Electrical Parts List
KA2-XU400000
R619 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R620 301 256 5614 MT-GLAZE 47 JA 1/10W
R621 301 326 1812 MT-GLAZE 8.2K D A 1/10W
R622 301 309 8517 MT-GLAZE 330 DA 1/10W
R623 401 360 8010 MT-GLAZE 470 DA 1/10W
R624 301 162 2912 MT-GLAZE 220 JA 1/10W
R625 301 256 5614 MT-GLAZE 47 JA 1/10W
R626 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R627 301 150 5918 MT-GLAZE 10K JA 1/10W
R628 301 150 5918 MT-GLAZE 10K JA 1/10W
R629 301 255 7312 MT-GLAZE 510K JA 1/10W
R631 301 255 7718 MT-GLAZE 11K JA 1/10W
R632 401 361 2314 MT-GLAZE 750K JA 1/3W
R633 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R634 301 256 1715 MT-GLAZE 33K JA 1/10W
R635 402 122 1802 OXIDE-MT 0.39JA 1W
302 099 6308 OXIDE-MT 0.39JA 1W
R636 301 162 3018 MT-GLAZE 22K JA 1/10W
R637 301 255 6117 MT-GLAZE 20K JA 1/10W
R638 301 256 6314 MT-GLAZE 47K JA 1/10W
R639 301 277 7215 MT-GLAZE 470 JA 1/3W
R640 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R641 301 150 5918 MT-GLAZE 10K JA 1/10W
R642 301 255 9514 MT-GLAZE 220K JA 1/10W
R643 301 150 5918 MT-GLAZE 10K JA 1/10W
R644 301 150 5918 MT-GLAZE 10K JA 1/10W
R646 301 256 7212 MT-GLAZE 18K JA 1/10W
R648 301 256 7212 MT-GLAZE 18K JA 1/10W
R651 301 150 5918 MT-GLAZE 10K JA 1/10W
R652 301 292 1915 MT-GLAZE 22 FA 1/2W
R662 301 152 3219 MT-GLAZE 330 JA 1/10W
R665 402 109 6806 OXIDE-MT 100KJA 2W
302 093 4805 OXIDE-MT 100KJA 2W
R671 301 256 7618 MT-GLAZE 3.9K JA 1/10W
R672 301 150 6212 MT-GLAZE 1K JA 1/10W
R673 301 264 2919 MT-GLAZE 12K FA 1/10W
R674 301 264 7518 MT-GLAZE 2.7K FA 1/10W
R675 301 162 3711 MT-GLAZE 4.7K JA 1/10W
R676 301 264 2810 MT-GLAZE 1.2K FA 1/10W
R683 301 265 0211 MT-GLAZE 390 FA 1/10W
R684 301 264 9314 MT-GLAZE 3.3K FA 1/10W
R692 301 037 5413 MT-GLAZE 1K JA 1/10W
R693 301 037 6717 MT-GLAZE 1.2K JA 1/10W
TRANSFORMER
!T651 645 097 6483 TRANS,POWER,PULSE
COIL
L611 945 081 4878 LINE FILTER
L612 645 089 2561 INDUCTOR,700U
L613 910 229 3532 CORE
L614 910 229 3532 CORE
L631 952 001 0124 CORE,PIPE
910 078 5954 PIPE CORE
L661 910 229 3532 CORE
L662 910 229 3532 CORE
L663 652 002 8500 INDUCTOR 330OHM, P
DIODE
D611 307 253 7405 DIODE FMXA-1106S
D611D 645 098 1715 CORE,FERRITE
D611E 645 098 1715 CORE,FERRITE
D612 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS355
D613 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS355
D631 307 163 0414 DIODE 1SS352-(TPH3)
307 149 0810 DIODE 1SS355-TE-17
408 062 7201 DIODE 1SS355
D632 307 247 8827 DIODE RF101L2S
D633 307 146 8116 DIODE EG01C
D651 307 247 8827 DIODE RF101L2S
D661 407 269 8400 DIODE FMEN-210A
407 267 3100 DIODE SG10SC9M
D662 407 269 8509 DIODE FMW-2106
407 267 3001 DIODE SG10SC6M
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D664 307 210 5416 DIODE RB551V-30-TE-17
D666 307 146 8116 DIODE EG01C
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
! F631 324 006 1305 FUSE 250V 2.5A
! PC661 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
! PC663 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
! PC671 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
PTH611 308 037 5501 THERMISTOR NTPDB5R0LDHB0
PTH641 408 062 4606 TH PRF18BD471QB1RB
ZD631 307 206 5413 ZD UDZS-TE-178.2B
ZD632 307 179 1214 ZENER DIODE PTZ13B-TE25
A630 655 004 1401 ASSY,PWB,FILTER KZ8AC
CAPACITOR
! C601 404 113 2904 MT-POLYEST 0.33U K 275V
! C602 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
! C603 304 073 3907 CERAMIC 1000P M 250V
! C604 304 073 3907 CERAMIC 1000P M 250V
RESISTOR
! R601 301 287 5416 MT-GLAZE 200K JA 1W
! R602 301 287 5416 MT-GLAZE 200K JA 1W
VARIABLE RESISTOR
! VA601 408 066 1700 VD TND14SE471KB0SLAA0
COIL
! L601 645 099 6825 LINE FILTER
! LF601 645 093 1765 SOCKET,INLET AC 3P
MISCELLANEOUS
! F601 423 034 4101 FUSE 250V 6.3A
323 021 7804 FUSE 250V 6.3A
A1000 655 004 1470 ASSY,PWB,MAIN KA2AC
TRANSISTOR
Q1001 406 021 7804 TR 2SC4617
Q1002 406 021 7804 TR 2SC4617
Q1003 305 217 7815 TR HN1B04FE-Y TE85L
Q1004 305 217 7815 TR HN1B04FE-Y TE85L
Q1005 406 021 7804 TR 2SC4617
Q1006 305 217 7815 TR HN1B04FE-Y TE85L
Q1007 406 021 7804 TR 2SC4617
Q1008 406 021 7804 TR 2SC4617
Q1021 406 021 7804 TR 2SC4617
To Next Page
