10
Top Control
qwe
r
t y u i
i INFO. button
Display the input source information (p.43).
t INPUT button
Select an input source (p.24).
e LAMP REPLACE indicator
Lights yellow light when the projection lamp reaches its
end of life (pp.49, 53).
w WARNING indicator
– Lights red light when the projector detects an abnormal
condition.
– Blinks red when the internal temperature of the
projector exceeds the operating range (pp.44, 53).
u OK button
Execute the item selected or use it to access the
submenu items (p.20).
y POINT ed7 8 buttons
Select an item or adjust the setting values in the On-
Screen Menu.
r MENU button
Open or close the On-Screen Menu (p.20).
q
POWER indicator
– Lights red while the projector is in stand-by mode.
– Lights green during operations.
– Blinks red during the cooling-off period.
– Blinks green in the Power management mode (p.41).
– Blinks orange when the automatic slide shutter is
closed during operations (p.53).
Part Names and Functions
o
o POWER ON/STAND-BY button
Turn the projector on or off (pp.18, 19).
