(2) Security Alarm（WDG71n）
Guide-light
Statue Instruction
WAN/LAN
Connect to xDSL/Fiber, Static IP, Dynamic IP, PPTP, L2TP, Wi-Fi ISP AP,
WiFi-AP
Power Outlet
Power supply 100V-240V
ZigBee/ Alarm
power Off Button
For ZigBee signal extend, it is also a button for turn on/off alarm
manually
Network Mode
Switch
 Please switch to the R mode while the RJ45 cable is connecting to the
xDSL modem and WDG71n
 Please switch to A mode while RJ45 cable is connecting to Sapido router
and WDG71n.
 Please switch to the W mode while connecting to Wi-Fi network by
Sapido router.
 Please switch to the R mode while connecting to the network by
other brand routers.
Reset Button
 Press over 10 seconds to factory default settings(like your Wi-Fi
password)
 Press about 3 seconds, the device will be rebooted
