Device Description
3 Device Description
3.1 Device Overview
2
7
8
1
3
4
9
5
6
6
Fig. 1: Semi-microbalance with motorized draft shield with ionizer and electronics module (example)
Pos. Name Description
1 Weighing chamber
2 Manufacturer’s ID label Not depicted
3 Weighing module
4 Electronics module Only for semi-microbalances with electronics module
5 Leveling foot Motorically adjustable
6 Palm-operated key Opens and closes the side and upper panel of the draft shield
7 Display and control unit
8 Operating display Touchscreen
9 Level
