Sartorius SIWABBP User Manual

Signum 1-2-3
Getting Started
§ A recessed space is provided in the scale base, accessed from the bottom of the scale,
for any excess length of cable.
§ Guide the connecting cable along the channel on the bottom of the weighing platform.
§ Use the cable clamps provided to affix the cable that connects the display and control
unit to the weighing platform to the bottom of the column.
§ Turn the weighing platform right side up and place it so that it rests on its feet.
§ Attach the cable retainer to affix the cable connecting the display and control unit to the
weighing platform to the back of the column.
SIWSBBS Installing the Display and Control Unit:
§
1 Slide the bracket under the weighing platform.
§
2 Press up into the openings.
§
3 Pull the bracket forward to lock into place.
§ Hang the display and control unit on the bracket.
7
3
1
2
3
2
1
