Sartorius SIWABBP User Manual

Signum 1-2-3
Operation
SIWR, SIWA models:
Geographical data
– Elevation and latitude or gravitational
acceleration displayed after Cal is
shown when the Signum is switched
on, if these values are supported by the
weighing encoder:
setup
utilit
8.12.: (show geographical data
before calibration/adjustment)
For each of these parameters, the term
is displayed first (Altitud, Latitud
or Gravity) for 1 second, and then
the corresponding value is displayed
continuously until you press ).
Note
When using verified weighing
instruments, the external adjustment
function can only be used when the
menu access switch is open once the
verification seal has been broken.
The device must then be verified again.
Internal calibration
For SIWS models only:
Verified versions or with option E7
In Setup (setup: :
wp-1: 1.9.) the
"internal calibration" option (setup:
wp-1: 1.9.4) must be set.
setup
wp-1
1. 9. Calibration,
Adjustment
1.9.1 * Ext. cal./
adjustment;
default weight
1.9.3 External cal./adjust-
ment; weight can
be selected under
menu item 1.18.1
1.9.4 Internal calibration/
adjustment
(models with
built-in motorized
calibration weight
only)
1.9.8 Setting the preload
1.9.9 Deleting the
preload
1.9.10 No function when
you press the
J key
1.10. Calibration/
Adjustment
sequence
1.10.1 Calibration
with automatic
adjustment
1.10.2 * Calibration with
manual adjustment
* = Factory setting
The scale housing has a built-in
motorized calibration weight.
The calibration/adjustment procedure
is performed as follows:
§ Select calibration/adjustment: Press the
J key
> The internal calibration weight is loaded
automatically
> The scale is adjusted
> If parameter 1.10.1 is selected in Setup
(
Setup: wp-1: 1.10.), the scale is
adjusted automatically
> If parameter 1.10.2 is selected in Setup
(
Setup: wp-1: 1.10.), the internal
calibration can be stopped without
adjusting the scale
> The internal calibration weight is
unloaded from the scale
> ISO/GMP-compliant record: see page 91
Setting the preload
Setup information
! It is only possible to set a preload when
the menu access switch is open.
– The J key must
be assigned the set preload function
(menu item 1.9.8)
! After setting a preload, close the menu
access switch and reallocate the original
function back to the J key (e.g.
external calibration/adjustment with
user-defined weights) under menu
item 1.9.
Deleting the preload
Setup information
! It is only possible to clear a preload
when the menu access switch
is open.
– The J key must
be set to the clear preload function
(menu item 1.9.9)
! After clearing the preload,
close the menu access switch and
reallocate the original function back to
the J key (e.g. external calibration/
adjustment with user-defined weights)
under menu item 1.9.
44
Operation
