Data Interface
88
Data Output Format
Each line in a print job can contain up to 22 characters (up to
20 printable characters plus two control characters). The first 6
characters, called the “data header”, identify the subsequent value.
You can suppress the header under menu item 7.2 in the
“Printouts” menu; in this case, the print job has up to 16 characters
(up to 14 printable characters plus two control characters).
Examples:
+ 235 pcs Without header
Qnt + 235 pcs With header
Display segments that are not activated are output as spaces.
Values with no decimal point are output without a decimal point.
Data Output Format with 16 Characters (without Data Header)
Normal Operation:
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * A A A A A A A A * E E E CR LF
or – * A A A A A A A A * E E E CR LF
or * * * * * * * * * * * * * * CR LF
+-: Plus or minus sign
*: Leerzeichen
A: Digit or letter (max. 7 characters plus decimal point)
E: Unit symbol
(1-3 letters followed by 2-0 spaces)
CR: Carriage return
LF: Line feed
Special Codes:
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * * * * – – * * * * * * CR LF
or * * * * * * H * * * * * * * CR LF
or * * * * * * H H * * * * * * CR LF
or * * * * * * L * * * * * * * CR LF
or * * * * * * L L * * * * * * CR LF
or * * * * * * C * * * * * * * CR LF
*: Space
– –: Final readout
H: Overload
HH: Overload in checkweighing
L: Underweight
LL: Underweight in checkweighing
C: Adjustment
Error Message:
P
os. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * E r r * * # # * * * * CR LF
o
r * * * E r r * # # # * * * * CR LF
*: Space
#: Error code number (2 or 3 digits)
Example (output of weight value of +1255.7 g):
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * * * 1 2 5 5 . 7 * g * * CR LF
Position 1: Plus +, or minus – or space
Position 2: Space
Positions 3-10: Weight value with decimal point; leading zeros are
output as spaces.
Position 11: Space
Positions 12-14: Characters for unit of measure or space
Position 15: Carriage return
Position 16: Line feed
Data Output Format with 22 Characters
(with Data Header)
Normal Operation:
P
os. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
K K K K K K + * A A A A A A A A * E E E CR LF
or K K K K K K - * A A A A A A A A * E E E CR LF
o
r * * * * * * * * * * * * * * * * * * * * CR LF
K
: ID code character, right-justified with spaces
+-: Plus or minus sign
*: Space
A: Digit or letter (max. 7 characters plus decimal point)
E: Unit symbol (1 to 3 letters followed by 2-0 spaces)
CR: Carriage return
LF: Line feed
Special Codes:
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * – – * * * * * * CR LF
or S t a t * * * * * * * * H * * * * * * * CR LF
or S t a t * * * * * * * * H H * * * * * * CR LF
or S t a t * * * * * * * * L * * * * * * * CR LF
or S t a t * * * * * * * * L L * * * * * * CR LF
or S t a t * * * * * * * * C * * * * * * * CR LF
*: Space – –: Final readout
H: Overload HH: Overload in checkweighing
L: Underweight LL: Underweight in checkweighing
C: Adjustment
