Satec PM130 series Reference Guide

13
4.8 Pulsing Setpoints
Table 4-15 Read Request
Message type (ASCII)
G
Message body (hexadecimal)
Request
Field Offset Length Parameter Range
1 0 2 Pulse output ID 0 (see Table 4-17)
Response
Field Offset Length Parameter Range
1 0 2 Pulse output ID 0 (see Table 4-17)
2 2 2 Output parameter ID see Table 4-18
3 4 4 For energy pulsing =
number of unit-hours per pulse,
otherwise - permanently set to 0
0-9999
Table 4-16 Write Request
Message type (ASCII)
g
Message body (hexadecimal)
Request/Response
Field Offset Length Parameter Range
1 0 2 Pulse output ID 0 (see Table 4-17)
2 2 2 Output parameter ID see Table 4-18
3 4 4 For energy pulsing =
number of unit-hours per pulse,
otherwise - set to 0
0-9999
Table 4-17 Pulse Outputs
Pulsing output ID Output allocation
0 Relay
Table 4-18 Pulsing Output Parameters
Pulsing parameter ID Identifier
None 0
kWh import 1
kWh export 2
kvarh import 4
kvarh export 5
kvarh total (absolute) 6
kVAh total 7

Satec PM130 series Specifications

General

Frequency Measurement Range	45-65 Hz
Power Measurement	Active, Reactive, Apparent Power per phase and total
Communication Ports	RS-485, Ethernet, USB
Protocols Supported	Modbus RTU, Modbus TCP, DNP3
Display	LCD
Mounting	DIN rail or panel mount
Digital Inputs/Outputs	4 digital inputs, 2 relay outputs
Humidity	5-95% non-condensing
