25
(E) available in the PM130E
Table 5-14 Setpoint Actions
Action ID (hex)
No action 0000h
Operate relay 3000h
Increment counter #1 4000h
Increment counter #2 4001h
Increment counter #3 4002h
Increment counter #4 4003h
Count operating time using counter #1
c
4400h
Count operating time using counter #2
c
4401h
Count operating time using counter #3
c
4402h
Count operating time using counter #4
c
4403h
c
This action converts a common event counter to the time counter which measures time at 0.1 hour
resolution while the setpoint is in the operated state. Each time counter has a non-volatile shadow counter
which counts time at 1 second resolution before the corresponding time counter is incremented.
5.7 Relay Operation Control Registers
These registers allow the user to manually override relay operation that is normally operated via
alarm setpoints.
A relay allocated as a pulsing relay may not be manually operated or released. When a relay is allocated
for pulsing, it automatically reverts to normal operation.
Table 5-15 Relay Operation Control Registers
Parameter Data
index
Length Direction Range
Relay control status 8400h 4 R/W see Table 5-16
Table 5-16 Relay Operation Status
Operation status ID
Normal operation 0
Force operate 1
Force release 2
5.8 Instrument Options Registers
Table 5-17 Instrument Options Registers
Parameter Data
index
Length Direction Range
Options 1 register 7F00h 4 R see Table 5-18
Options 2 register 7F01h 4 R see Table 5-18
Table 5-18 Instrument Options
Options register Bit Description
Options1 0 120V option
1 690V option
2-4 Reserved
5 150% current over-range
6-8 Reserved
9 Relays option
