Satec PM130 series Reference Guide

24
Trigger parameter Trigger
index (hex)
Unit Range c
Low current 8D01h A 0 to Imax
Reserved 0E07h
Reserved 0E08h
Reserved 0E09h
Reserved 0E0Ah
High/low real-time auxiliary values
High frequency
e
1002h 0.01 Hz 0 to 10000
Low frequency
e
9002h 0.01 Hz 0 to 10000
High/low average values per phase
High current L1 1103h A 0 to Imax
High current L2 1104h A 0 to Imax
High current L3 1105h A 0 to Imax
Low current L1 9103h A 0 to Imax
Low current L2 9104h A 0 to Imax
Low current L3 9105h A 0 to Imax
High/low average values on any phase
High voltage
f
1300h V 0 to Vmax
Low voltage
f
9200h V 0 to Vmax
High current 0301h A 0 to Imax
Low current 8201h A 0 to Imax
High/low average total values (P)
High total kW import 1406h kW 0 to Pmax
High total kW export 1407h kW 0 to Pmax
High total kvar import 1408h kvar 0 to Pmax
High total kvar export 1409h kvar 0 to Pmax
High total kVA 1402h kVA 0 to Pmax
Low total PF lag 9404h 0.001 0 to 1000
Low total PF lead 9405h 0.001 0 to 1000
High/low average auxiliary values
High neutral current 1501h A 0 to Imax
High frequency
e
1502h 0.01 Hz 0 to 10000
Low frequency e 9502h 0.01 Hz 0 to 10000
High present demands
High volt demand L1/L12 (P)
f
1600h V 0 to Vmax
High volt demand L2/L23 (P)
f
1601h V 0 to Vmax
High volt demand L3/L31 (P)
f
1602h V 0 to Vmax
High ampere demand L1 1603h A 0 to Imax
High ampere demand L2 1604h A 0 to Imax
High ampere demand L3 1605h A 0 to Imax
High block kW demand (E) 1606h kW 0 to Pmax
High block kVA demand (E) 1608h kVA 0 to Pmax
High sliding window kW demand (E) 1609h kW 0 to Pmax
High sliding window kVA demand (E) 160Bh kVA 0 to Pmax
High accumulated kW demand (E) 160Fh kW 0 to Pmax
High accumulated kVA demand (E) 1611h kVA 0 to Pmax
Predicted kW demand (import) (E) 1612h kW 0 to Pmax
Predicted kVA demand (E) 1614h kVA 0 to Pmax
c
For parameter limits, see Note
c
to Table 4-1
d
The setpoint is operated when the actual phase sequence does not match the indicated phase rotation
e
The actual frequency range is 45.00 - 65.00 Hz
f
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other
wiring mode, they will be line-to-line voltages.
(P) available in the PM130P and PM130E

Satec PM130 series Specifications

General

Frequency Measurement Range	45-65 Hz
Power Measurement	Active, Reactive, Apparent Power per phase and total
Communication Ports	RS-485, Ethernet, USB
Protocols Supported	Modbus RTU, Modbus TCP, DNP3
Display	LCD
Mounting	DIN rail or panel mount
Digital Inputs/Outputs	4 digital inputs, 2 relay outputs
Humidity	5-95% non-condensing
