Satec PM130 series Reference Guide

21
Parameter Data
index
Length Direc-
tion
Unit Range c
Voltage L1/L12
f
3400h 8 R V 0 to Vmax
Voltage L2/L23
f
3401h 8 R V 0 to Vmax
Voltage L3/L31
f
3402h 8 R V 0 to Vmax
Current L1 (P) 3403h 8 R A 0 to Imax
Current L2 (P) 3404h 8 R A 0 to Imax
Current L3 (P) 3405h 8 R A 0 to Imax
Maximum real-time total values (M) (P)
Total kW 3500h 8 R kW -Pmax to Pmax
Total kvar 3501h 8 R kvar -Pmax to Pmax
Total kVA 3502h 8 R kVA 0 to Pmax
Total PF
d
3503h 4 R 0.001 0 to 1000
Maximum real-time auxiliary values (M)
Reserved 3600h 8 R 0
Neutral current (P) 3601h 8 R A 0 to Imax
Frequency (P)
e
3602h 4 R 0.01 Hz 0 to 10000
Maximum demands (M)
Max. volt demand L1/L12 (P)
f
3700h 8 R 0 to Vmax
Max. volt demand L2/L23 (P)
f
3701h 8 R 0 to Vmax
Max. volt demand L3/L31 (P)
f
3702h 8 R 0 to Vmax
Max. ampere demand L1 3703h 8 R A 0 to Imax
Max. ampere demand L2 3704h 8 R A 0 to Imax
Max. ampere demand L3 3705h 8 R A 0 to Imax
Reserved 3706h 8 R 0
Reserved 3707h 8 R 0
Reserved 3708h 8 R 0
Maximum sliding window kW
demand (E)
3709h 8 R kW 0 to Pmax
Reserved 370Ah 8 R 0
Maximum sliding window kVA
demand (E)
370Bh 8 R kVA 0 to Pmax
c
For parameter limits, see Note
c
to Table 4-1
d
New absolute min/max value (lag or lead)
e
The actual frequency range is 45.00 - 65.00 Hz
f
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other
wiring mode, they will be line-to-line voltages.
(M)
These parameters are logged to the Min/Max log
(P)
available in the PM130P and PM130E
(E)
available in the PM130E
5.3 Basic Setup Registers
Table 5-8 Basic Setup Registers
Parameter Data
index
Length Direction Range
Wiring mode c 8600h 4 R/W 0 = 3OP2, 1 = 4LN3,
2 = 3DIR2, 3 = 4LL3,
4 = 3OP3, 5 = 3LN3,
6 = 3LL3
PT ratio 8601h 4 R/W
10 to 65000 × 0.1
CT primary current 8602h 4 R/W 1 to 50000 A
Power demand period (E) 8603h 4 R/W 1,2,5,10,15,20,30,60 min
255 = external
synchronization
d
Volt/ampere demand period 8604h 4 R/W 1 to 1800 sec
Averaging buffer size 8605h 4 R/W 8, 16, 32
Reset enable/disable 8606h 4 R/W 0 = disable, 1 = enable

Satec PM130 series Specifications

General

Frequency Measurement Range	45-65 Hz
Power Measurement	Active, Reactive, Apparent Power per phase and total
Communication Ports	RS-485, Ethernet, USB
Protocols Supported	Modbus RTU, Modbus TCP, DNP3
Display	LCD
Mounting	DIN rail or panel mount
Digital Inputs/Outputs	4 digital inputs, 2 relay outputs
Humidity	5-95% non-condensing
