1 GENERAL
This document specifies the ASCII serial communications protocol used to transfer data
between a master computer station and the PM130. The document provides the complete
information necessary to develop a third-party communications software capable of
communication with the Series PM130 instruments.
All messages within the ASCII communications protocol are designed to consist only of
printable characters.
Additional information concerning communications operation, configuring the communications
parameters and communications connections is found in "Series PM130 Powermeters,
Installation and Operation Manual".
IMPORTANT
In 3-wire connection schemes, the unbalanced current and phase readings for power factor, active power,
and reactive power will be zeros, because they have no meaning. Only the total three-phase power values
can be used.

Satec PM130 series Specifications

General

Frequency Measurement Range	45-65 Hz
Power Measurement	Active, Reactive, Apparent Power per phase and total
Communication Ports	RS-485, Ethernet, USB
Protocols Supported	Modbus RTU, Modbus TCP, DNP3
Display	LCD
Mounting	DIN rail or panel mount
Digital Inputs/Outputs	4 digital inputs, 2 relay outputs
Humidity	5-95% non-condensing
