20
Parameter Data
index
Length Direc-
tion
Unit Range c
kvarh import (inductive) L2 1804h 8 R kvarh 0 to 10
8
-1
kvarh import (inductive) L3 1805h 8 R kvarh 0 to 10
8
-1
kVAh L1 1806h 8 R kVAh 0 to 10
8
-1
kVAh L2 1807h 8 R kVAh 0 to 10
8
-1
kVAh L3 1808h 8 R kVAh 0 to 10
8
-1
Reserved
Reserved 2900h 8 R
Reserved 2901h 8 R
Reserved 2902h 8 R
Reserved 2903h 8 R
Reserved 2904h 8 R
Reserved 2905h 8 R
Reserved 2906h 8 R
Reserved 2907h 8 R
Reserved 2908h 8 R
Reserved 2909h 8 R
Reserved 290Ah 8 R
Reserved 290Bh 8 R
Reserved 290Ch 8 R
Reserved 290Dh 8 R
Reserved 290Eh 8 R
Reserved 290Fh 4 R
Reserved 2910h 4 R
Reserved 2911h 4 R
Reserved
Reserved 2A00h 8 R
Reserved 2A01h 8 R
Reserved 2A02h 8 R
Reserved 2A03h 4 R
Minimum real-time values per phase (M)
Voltage L1/L12 f 2C00h 8 R V 0 to Vmax
Voltage L2/L23
f
2C01h 8 R V 0 to Vmax
Voltage L3/L31
f
2C02h 8 R V 0 to Vmax
Current L1 (P) 2C03h 8 R A 0 to Imax
Current L2 (P) 2C04h 8 R A 0 to Imax
Current L3 (P) 2C05h 8 R A 0 to Imax
Minimum real-time total values (M) (P)
Total kW 2D00h 8 R kW -Pmax to Pmax
Total kvar 2D01h 8 R kvar -Pmax to Pmax
Total kVA 2D02h 8 R kVA 0 to Pmax
Total PF
d
2D03h 4 R 0.001 0 to 1000
Minimum real-time auxiliary values (M)
Reserved 2E00h 8 R 0
Neutral current (P) 2E01h 8 R A 0 to Imax
Frequency (P)
e
2E02h 4 R 0.01 Hz 0 to 10000
Minimum demands (M) - Reserved
Reserved 2F00h 8 R 0
Reserved 2F01h 8 R 0
Reserved 2F02h 8 R 0
Reserved 2F03h 8 R 0
Reserved 2F04h 8 R 0
Reserved 2F05h 8 R 0
Reserved 2F06h 8 R 0
Reserved 2F07h 8 R 0
Reserved 2F08h 8 R 0
Reserved 2F09h 8 R 0
Reserved 2F0Ah 8 R 0
Reserved 2F0Bh 8 R 0
Maximum real-time values per phase (M)
