Satec PM130 series Reference Guide

19
Parameter Data
index
Length Direc-
tion
Unit Range c
Reserved 111Bh 4 R
Reserved 111Ch 4 R
Reserved 111Dh 4 R
Voltage L12 110Eh 8 R V 0 to Vmax
Voltage L23 110Fh 8 R V 0 to Vmax
Voltage L31 1120h 8 R V 0 to Vmax
Average total values (P)
Total kW 1400h 8 R kW -Pmax to Pmax
Total kvar 1401h 8 R kvar -Pmax to Pmax
Total kVA 1402h 8 R kVA 0 to Pmax
Total PF 1403h 4 R 0.001 -999 to 1000
Reserved 1404h 4 R 0
Reserved 1405h 4 R 0
Average auxiliary values
Reserved 1500h 8 R 0
Neutral current 1501h 8 R A 0 to Imax
Frequency
e
1502h 4 R 0.01 Hz 0 to 10000
Voltage unbalance (P) 1503h 4 R % 0 to 300
Current unbalance (P) 1504h 4 R % 0 to 300
Present demands
Volt demand L1/L12 (P)
f
1600h 8 R V 0 to Vmax
Volt demand L2/L23 (P)
f
1601h 8 R V 0 to Vmax
Volt demand L3/L31 (P)
f
1602h 8 R V 0 to Vmax
Ampere demand L1 1603h 8 R A 0 to Imax
Ampere demand L2 1604h 8 R A 0 to Imax
Ampere demand L3 1605h 8 R A 0 to Imax
Block kW demand (E) 1606h 8 R kW 0 to Pmax
Reserved 1607h 8 R 0
Block kVA demand (E) 1608h 8 R kVA 0 to Pmax
Sliding window kW demand (E) 1609h 8 R kW 0 to Pmax
Reserved 160Ah 8 R 0
Sliding window kVA demand (E) 160Bh 8 R kVA 0 to Pmax
Reserved 160Ch 8 R 0
Reserved 160Dh 8 R 0
Reserved 160Eh 8 R 0
Accumulated kW demand (E) 160Fh 8 R kW 0 to Pmax
Reserved 1610h 8 R 0
Accumulated kVA demand (E) 1611h 8 R kVA 0 to Pmax
Predicted sliding window kW
demand (E)
1612h 8 R kW 0 to Pmax
Reserved 1613h 8 R 0
Predicted sliding window kVA
demand (E)
1614h 8 R kVA 0 to Pmax
PF at maximum sliding window
kVA demand (E)
1615h 4 R 0.001 0 to 1000
Total energies (E)
kWh import 1700h 8 R kWh 0 to 10
8
-1
kWh export 1701h 8 R kWh 0 to 10
8
-1
Reserved 1702h 8 R 0
Reserved 1703h 8 R 0
kvarh import 1704h 8 R kvarh 0 to 10
8
-1
kvarh export 1705h 8 R kvarh 0 to 10
8
-1
Reserved 1706h 8 R 0
Reserved 1707h 8 R 0
kVAh total 1708h 8 R kVAh 0 to 10
8
-1
Phase energies (E)
kWh import L1 1800h 8 R kWh 0 to 10
8
-1
kWh import L2 1801h 8 R kWh 0 to 10
8
-1
kWh import L3 1802h 8 R kWh 0 to 10
8
-1
kvarh import (inductive) L1 1803h 8 R kvarh 0 to 10
8
-1

Satec PM130 series Specifications

General

Frequency Measurement Range	45-65 Hz
Power Measurement	Active, Reactive, Apparent Power per phase and total
Communication Ports	RS-485, Ethernet, USB
Protocols Supported	Modbus RTU, Modbus TCP, DNP3
Display	LCD
Mounting	DIN rail or panel mount
Digital Inputs/Outputs	4 digital inputs, 2 relay outputs
Humidity	5-95% non-condensing
