18
Parameter Data
index
Length Direc-
tion
Unit Range c
kVA L3 0C0Eh 8 R kVA 0 to Pmax
Power factor L1 0C0Fh 4 R 0.001 -999 to 1000
Power factor L2 0C10h 4 R 0.001 -999 to 1000
Power factor L3 0C11h 4 R 0.001 -999 to 1000
Reserved 0C12h 4 R
Reserved 0C13h 4 R
Reserved 0C14h 4 R
Reserved 0C15h 4 R
Reserved 0C16h 4 R
Reserved 0C17h 4 R
Reserved 0C18h 4 R
Reserved 0C19h 4 R
Reserved 0C1Ah 4 R
Reserved 0C1Bh 4 R
Reserved 0C1Ch 4 R
Reserved 0C1Dh 4 R
Voltage L12 0C1Eh 8 R V 0 to Vmax
Voltage L23 0C1Fh 8 R V 0 to Vmax
Voltage L31 0C20h 8 R V 0 to Vmax
Real-time total values (P)
Total kW 0F00h 8 R kW -Pmax to Pmax
Total kvar 0F01h 8 R kvar -Pmax to Pmax
Total kVA 0F02h 8 R kVA 0 to Pmax
Total PF 0F03h 4 R 0.001 -999 to 1000
Reserved 0F04h 4 R 0
Reserved 0F05h 4 R 0
Real-time auxiliary values
Reserved 1000h 8 R 0
Neutral current 1001h 8 R A 0 to Imax
Frequency e 1002h 4 R 0.01 Hz 0 to 10000
Voltage unbalance (P) 1003h 4 R % 0 to 300
Current unbalance (P) 1004h 4 R % 0 to 300
Average values per phase (power values - P)
Voltage L1/L12
f
1100h 8 R V 0 to Vmax
Voltage L2/L23
f
1101h 8 R V 0 to Vmax
Voltage L3/L31
f
1102h 8 R V 0 to Vmax
Current L1 1103h 8 R A 0 to Imax
Current L2 1104h 8 R A 0 to Imax
Current L3 1105h 8 R A 0 to Imax
kW L1 1106h 8 R kW -Pmax to Pmax
kW L2 1107h 8 R kW -Pmax to Pmax
kW L3 1108h 8 R kW -Pmax to Pmax
kvar L1 1109h 8 R kvar -Pmax to Pmax
kvar L2 110Ah 8 R kvar -Pmax to Pmax
kvar L3 110Bh 8 R kvar -Pmax to Pmax
kVA L1 110Ch 8 R kVA 0 to Pmax
kVA L2 110Dh 8 R kVA 0 to Pmax
kVA L3 110Eh 8 R kVA 0 to Pmax
Power factor L1 110Fh 4 R 0.001 -999 to 1000
Power factor L2 1110h 4 R 0.001 -999 to 1000
Power factor L3 1111h 4 R 0.001 -999 to 1000
Reserved 1112h 4 R
Reserved 1113h 4 R
Reserved 1114h 4 R
Reserved 1115h 4 R
Reserved 1116h 4 R
Reserved 1117h 4 R
Reserved 1118h 4 R
Reserved 1119h 4 R
Reserved 111Ah 4 R
