Chapter 6 Viewing Status Information 61
Page Window Parameter Digits Unit
15 1 DLG.7 Label
15 2 Number of records in Data log #7 4
15 3 Data log #7 percent full 3
16 1 DLG.8 Label
16 2 Number of records in Data log #8 4
16 3 Data log #8 percent full 3
17 1 FLG.1 Label
17 2 Number of records in Waveform log #1 4
17 3 Waveform log #1 percent full 3
18 1 FLG.2 Label
18 2 Number of records in Waveform log #2 4
18 3 Waveform log #2 percent full 3
19 1 bAtt Label
19 3 The battery status (NORMAL/LOW)
