18 Chapter 3 Using the Menus
Chapter 3 Using the Menus
3. Chapter 3 Using the Menus
Press and release to enter the setup mode. The primary menus
will appear:
Press again to activate the window of the desired primary menu.
Press
Select CHG to initialize or modify the instrument setup, or to clear the accumulated
values stored in the instrument. Entry to this menu can be protected by a
password.
Select StA to view extended status information which may be useful during
installation and in certain applications.
Select OPS for viewing (not editing) the instrument setup options.
After selecting either OPS or CHG, the list of setup menus is displayed in
the upper window. Figure 3-1 presents a complete menu list. Depending
on the model of your instrument, some menus may not appear.
Password
The Setup Change Menu can be secured by a user-defined password
comprised of 4 digits. The instrument is shipped with password protection
disabled. To enable password protection, go to the Access Control Menu
(see Section 4.14).
The Password Menu appears if password protection is enabled.
To enter a password:
9 Set the first digit using the up and down arrow keys.
9 Press to advance to the next digit.
9 Set the other password digits in the same manner.
9 Press to continue setup. If your password is incorrect,
you will return to the Primary Selection Menu.
Î
Î
Î
Î
Î
Î
SELECT
SELECT
ENTER
SELECT
StA
ENTER
SELECT
CHG
ENTER
SELECT
OPS
ENTER
StA
CHG
OPS
- Status Information Menu (see Chapter 6)
- Setup Options Menu
- Setup Change Menu (see Chapter 4)
PASS
0000
SELECT
ENTER
