Chapter 4 Setup Menus 31
3. If a relay you allocated for pulsing has been engaged by an alarm/event
setpoint, the setpoint is automatically disabled.
4.8 Alarm/Event Setpoints Setup Menu
Î Î Î Î
This menu is used to specify the events to be monitored by the setpoints,
and actions to be triggered by those events.
Your instrument provides 16 alarm/event setpoints that can monitor a
wide variety of events; in turn, these events can be programmed to trigger
specific actions. Each setpoint can contain up to four trigger conditions
combined by logical operators OR and AND, up to four setpoint actions,
and optional operate and release delays. For more information on using
setpoints, see Appendix B Using Setpoints.
Table 4-6 explains the setpoint setup parameters. For the entire list of
available triggers and setpoint actions, refer to Tables 4-7 and 4-8.
Example:
First trigger
parameter
Setpoint 1 is set to monitor the real-time
high current on phase 1 (the first
trigger parameter).
Operate limit for
the first trigger
Release limit
for the first
trigger
The operate (On) and release (OFF)
limits which determine setpoint
operation are defined as 1200A and
1100A respectively.
First setpoint
action
The first action to be triggered is
operation of relay #1.
Operate delay
Release delay
The delays before operation (On d)
and release (OFFd) are set at 5
seconds and 10 seconds respectively.
SP 1
RtHi.C1
trG.1
SP 1
5
On d
SP 1
10
OFFd
SP 1
1200
On.1
SP 1
rEL.1
A
ct.1
SP 1
1100
OFF.1
SELECT
CH
G
SEtP
Ï
Ð
ENTER ENTER
