Satec PM172EH series User Manual

22 Chapter 4 Setup Menus
2
The waveform recorder #1 logs waveforms in series of records. A
compound waveform can have as many as 1280 cycles recorded in 80
consequent records, each record comprising 16 waveform cycles.
NOTES
1. The maximum value for CT PRIMARY CURRENT × PT RATIO is 10,000,000. If this
product is greater, power related values will be zeroed.
2. Always specify WIRING MODE, PT RATIO and CT PRIMARY CURRENT prior to
setting up alarm setpoints and analog output channels, otherwise the alarm/event
setpoints and analog outputs, which use these parameters, will automatically be
disabled.
4.2 Communications Port Setup Menus
Î Î Î Î
Î Î Î Î
These menus allow you to access the communications port options for
communication with a master computer. Table 4-2 lists the communications
options and their code names.
From the main menu, select the menu for the port you want to configure.
To select and view a setup
option:
9 Press to activate the
middle window.
9 Use the up/down arrow keys
to scroll to the desired
option. The option setting will
appear in the lower window.
To change the selected option:
9 Press to activate the
lower window.
9 Use the up/down arrow keys to scroll to the desired
value.
9 Press to store the selected value or press
to quit the setup menu.
NOTE: An optional analog expander can be connected to Port #2.
Prt.1
ASCII
Prot
SELECT
CH
G
ENTER
Prt.1
Ï
Ð
ENTER
ENTER
ESC
SELECT
CH
G
ENTER
Prt.
2
Ï
Ð
ENTER
SELECT
SELECT
