Chapter 4 Setup Menus 47
Store your password in a safe place. If you cannot
provide the correct password, contact your local
distributor for the super-user password to override
password protection.
4.15 Reset Menu
Î Î Î Î
This menu allows you to reset to zero the accumulators and Min/Max
registers in your instrument. The menu can only be accessed via the
Setup Change Menu (CHG). If the reset is disabled from the Basic Setup
Menu (see Section 4.1), you will not be able to enter this menu.
The following designations are used in the menu to specify a data location
to be reset:
Lo.Hi Resets Min/Max registers (does not affect maximum demands)
A.dnd Resets volt/ampere maximum demands
P.dnd Resets total power maximum demands
dnd Resets all total maximum demands
EnrG Resets total and phase energies
tOU.E Resets the TOU energy registers
tOU.d Resets the TOU maximum demand registers
Cnt Resets all pulse counters
Cnt.1 Resets counter # 1
Cnt.2 Resets counter # 2
Cnt.3 Resets counter # 3
Cnt.4 Resets counter # 4
To reset the desired locations:
9 Press to activate the middle window, and then use the
up/down arrow keys to scroll to the desired data location entry
9 Press to activate the lower window.
9 Press and hold for about 5 seconds until the do label
is replaced with done, and then release the key. You will return to
the middle window.
To quit the reset menu:
9 Press .
SELECT
CH
G
rSt
Ï
Ð
ENTERENTER
SELECT
SELECT
ENTER
ESC
rSt
do
EnrG
