SATEL VERSA 27
1. In the “Zones/Outputs” tab, click on the “Read” button to read the data related to wireless
devices from the controller (these data are not read after clicking on the button in
the main menu).
2. Click on the zone to which a new wireless device is to be assigned (you can also select
the zone later in the “New wireless dev.” window).
3. Click on the “New device” button. The “New wireless dev.” window will open.
4. Enter the 7-digit serial number of the added device. The serial number can be found on
the electronics board or on the enclosure. Each ARF-100 radio signal level tester has
serial number 0000500.
5. Depending on the device type:
ACX-200 / ACX-201: power-up the expander,
ARF-100: turn on the device,
ASW-100 E / ASW-100 F: insert the controller into 230 V AC socket,
other devices: open the tamper contact.
6. The message will confirm that a new device has been added (unless you have entered an
invalid serial number, of which you will be informed by a message). The new zone name
will be displayed. You can change it. The same name will also be given to the output, if
the device is assigned to the output.
7. Click on the “OK” button (you can click on the “Quit” button to cancel adding a new device
or on the “Next” button to proceed to adding a next wireless device).
8. Click on the “Write” button to write the new wireless device data to the controller (these
data will not be written after clicking on the button in the main menu).
LCD keypad
You can add ABAX wireless devices in the service mode by means of the NEW DEVICE
function (SERVICE MODE 2. HARDWARE 1. KPDS. & EXPS. 3. WIRELESS MOD. 1. NEW
DEVICE
).
1. Having started the function, enter the 7-digit serial number of the added device and press
the key. The serial number can be found on the electronics board or on the
enclosure. Each ARF-100 radio signal level tester has serial number 0000500.
2. When the “Open device tamper” message is displayed, depending on the device type:
ACX-200 / ACX-201: power-up the expander,
ARF-100: turn on the device,
ASW-100 E / ASW-100 F: insert the controller into 230 V AC socket,
other devices: open the tamper contact.
3. Information on the device to be added will be displayed (if nothing happens, it can mean
that you have entered an invalid serial number – if this is the case, press to return
to the submenu). Press to confirm your intention to add a device.
4. Using the and keys, select the zone to which the device is to be assigned
and then press .
5. The new name of the zone will be displayed. You can change it. The same name will also
be given to the output, if the device is assigned to the output. Press
to save the
name. If the device takes up several positions, the name-giving procedure must be
repeated for them.
6. In the next steps, you can configure the device (see the P
ROGRAMMING manual).
