SATEL VERSA 7
 LEDs indicating the status of the partitions and the system.
 12 keys, bearing designations according to telephone standard and intended for entering
data.
 4 additional keys for menu navigation and arming/disarming.
 Backlit keys.
 Built-in proximity card reader. VERSA-LCDR
 Tamper contact reacting to the enclosure opening or detaching from the wall.
4. Expansion modules
ETHM-1 Plus / ETHM-1. Ethernet communication module. Enables reporting events as
well as operating and programming the control panel via the Ethernet network.
INT-RX-S / INT-RX. 433 MHz keyfobs receiver expansion module. Enables operation of
the alarm system using the 433 MHz keyfobs.
VERSA-MCU. 433 MHz wireless system controller. Enables the alarm system to be
operated using the 433 MHz keyfobs and the 433 MHz wireless detectors to be used in
the alarm system.
ACU-120 / ACU-270 / ACU-100 / ACU-250. ABAX wireless system controller. Enables the
alarm system to be operated using the ABAX keyfobs and the ABAX bidirectional
wireless devices to be used in the alarm system.
INT-E / CA-64 E / CA-64 EPS. Zone expander. Adds 8 programmable hardwired zones to
the security system.
INT-O / INT-ORS / CA-64 O / CA-64 OPS. Output expander. Adds 8 programmable
hardwired outputs to the security system.
INT-CR / INT-IT-2 / INT-IT. Proximity card arm/disarm device. Enables arming / disarming
and alarm clearing in partitions by means of proximity cards, proximity tags and other
passive transponders.
CA-64 SM. Voice synthesizer expander. It can store 16 voice messages for telephone
messaging.
INT-VG. Voice module. Allows remote operation of the control panel from the telephone
keypad (interactive voice menu). It can store 16 voice messages for telephone
messaging.
5. System installation
Disconnect power before making any electrical connections.
The following tools will be useful during installation:
 blade screwdriver 2.5 mm,
 Phillips screwdriver,
 precision pliers,
 flat nose pliers,
 drill with a set of drill bits.
5.1 Installation plan
The installation must be preceded by preparation of a plan of the security alarm system. It is
advisable to draw up a sketch of the premises and mark on it all the devices that are to be
