6 VERSA SATEL
– firmware update for the control panel.
Electrical protection of all hardwired zones and outputs, and communication bus.
Switching power supply with short-circuit protection, provided with a battery status
supervision and low battery disconnect system.
3. Keypads
SATEL offers the following keypads for VERSA alarm control panels:
INT-TSG – hardwired touchscreen keypad,
INT-TSH – hardwired touchscreen keypad,
VERSA-LCD – hardwired LCD keypad with mechanical keys,
VERSA-LCDM – hardwired LCD keypad with mechanical keys,
VERSA-LCDR – hardwired LCD keypad with mechanical keys and built-in proximity card
reader,
VERSA-LCDM-WRL – wireless LCD keypad with mechanical keys and built-in proximity card
reader (supported by ACU-120 and ACU-270 controllers),
VERSA-LED – hardwired LED keypad with mechanical keys.
The keypads are also available with different color options for display and backlight of keys.
The color variant is indicated by the additional designation in the keypad name (e.g.
VERSA-LCD-GR – green display and keys backlight; VERSA-LCDM-WH – white display and
keys backlight).
For information on the INT-TSG, INT-TSH and VERSA-LCDM-WRL keypads, please
refer to the manuals delivered with the keypads.
Fig. 1. Examples of keypads supported by the VERSA control panel.
3.1 Keypads features
Display 2 x 16 characters with backlight. VERSA-LCD / VERSA-LCDM / VERSA-LCDR
LEDs indicating the status of the zones. VERSA-LED
