Section 1: Introduction
Page 1-4 CG4 Series Operator Manual
1.3 PARTS IDENTIFICATION (cont’d)
9
USB and RS232C interface on-board
10
USB and LAN interface on-board
USB and IEEE interface on-board
11
10
10
11
11
12
13
14
Back view
Media inlet
An opening for Fan-folded media or media
from unwinder to feed in to the printer.
DC input power terminal
Supplies power to the printer by inserting the
power cable via the AC adapter.
USB interface terminal
To connect printer to the host computer using
the USB interface.
RS-232C interface terminal
To connect printer to the host computer using
RS-232C interface.
Or, to connect the optional Keypad, Scanner or
Smart keyboard to the printer.
LAN interface terminal
To connect printer to the host computer using
LAN interface.
IEEE interface terminal
To connect printer to the host computer using
IEEE interface.
9
10
11
12
13
14

SATO CG408 Specifications

General

Resolution	203 dpi
Max Print Width	104 mm
Print Method	Thermal Transfer
Max Print Speed	4 inches/sec
Media Roll Diameter	127 mm (5 inches)
Memory	4 MB Flash
Interface	USB, Serial, Ethernet
Media Sensor	Reflective and Transmissive
Media Thickness	0.06 mm - 0.19 mm
Ribbon Length	100 m (328 ft)
Label Thickness Range	0.06 mm - 0.19 mm
