Section 6: General Specifications
CG4 Series Operator Manual Page 6-1
GENERAL SPECIFICATIONS
6.1 PRINTER BASIC SPECIFICATIONS
MODEL NAME
CG408 DT CG412 DT CG408 TT CG412 TT
PHYSICAL CHARACTERISTICS
Width 7.05” (179 mm)
Depth 9.37” (238 mm)
Height 6.81” (173 mm)
Weight 3.7 lbs. (1.7 kg) 4.19 lbs. (1.9 kg)
POWER SUPPLY (AC ADAPTER)
Input Voltage 100-240 V AC, +/-10%, 50/60 Hz (Full range)
Output Voltage 19 V DC, +/-5%, 3.86A
Power Consumption
At peak times: 50 Watts
During standby: 2.5 Watts
ENVIRONMENTAL (EXCLUDING MEDIA)
Operating Temperature 39.2 to 100.4°F (4° to 38°C)
Storage Temperature 14 to 140°F (-10° to 60°C)
Operating Humidity 30 to 80% RH, Non-condensing
Storage Humidity 15 to 85% RH, Non-condensing
PRINT
Method DT models: Direct Thermal only
TT models: Thermal Transfer and Direct
Thermal
Print Speed (selectable)
2, 3 or 4 Inches/second (Setting: 2, 3, 4)
(50, 75 or 100 mm/second)
*Maximum print speed varies depending on the of media used.
Resolution
(203 Dots Per
Inch) 8 dots/mm
(305 Dots Per
Inch) 12 dots/mm
(203 Dots Per
Inch) 8 dots/mm
(305 Dots Per
Inch) 12 dots/mm
Maximum Print Width 4.09” (104 mm)
Maximum Print Length 11.81” (300 mm)
