Section 3: Operation and Configuration
Page 3-16 CG4 Series Operator Manual
3.8 DEFAULT SETTING MODE
When default setting mode is selected and executed in Operation Setting mode (refer to Section 3.5
Operation Setting Mode), the printer will reset to the default setting (factory preset) as listed below.
*1. To be connected by Port1024 and Port1025 (2 port connections) or Port 9100 (1 port connection)
No. Items to be reset Default value
1 Offset (V, H) Vertical = 0 dot, Horizontal = 0 dot
2 Pitch Offset 0 dot
3 Cut Offset 0 dot
4 Dispensing Offset 0 dot
5 Tear-Off Offset 0 dot
6 Label Size Pitch 896 dot x Width 832 dot [203 dpi]
Pitch 1344 dot x Width 1248 dot [305 dpi]
7 Print Speed 75 mm/sec (3 Inches/sec)
8 Print Darkness 3A
9 Sensor Type Gap
10 Paper End Search Roll
11 Zero Slash Enabled
12 Proportional Pitch Enabled
13 Initial Feed Disabled
14 Auto Feed Disabled
15 Operation mode Continuous - (No setting)
Tear Off - (No setting)
Cutter Mode 1 (Head position)
Dispenser Mode 1 (Head position)
16 Interface RS-232C Baud rate=19200 bps, Protocol = Protocol for
driver
LAN Protocol for driver (ENQ response mode) *1
IEEE 1284 Protocol = Protocol for driver
USB Protocol = Protocol for driver
To Next Page
