Section 3: Operation and Configuration
CG4 Series Operator Manual Page 3-19
*1. Available for USB+RS-232C specification only.
*2. Available for USB+LAN specification only.
*3. Use SATO port or Port 9100 when sending print request from the printer driver.
*4. Available for IEEE1284+USB specification only.
*5. The printer will restart in specified mode.
22 RS-232C interface
*1
Baud rate 9600/19200/38400bps
23 Data bit 7/8 bit
24 Parity No parity/Odd number/Even number
25 Stop bit 1/2 bit
26 Control READY/BUSY control (single item buffer),
READY/BUSY control (multi buffer), Xon/Xoff,
Protocol for driver(STATUS4), STATUS3
27 LAN interface *2 LAN mode Protocol for driver(STATUS4)Cyclic response *3
Protocol for driver(STATUS4)ENQ response *3
1 port connection/ENQ response(STATUS3)
28 IEEE 1284 inter-
face *4
Buffer type Multi/ 1 item
ACK width 010 to 200 (1=50ns)
28 Non-standard code Nonstandard code
switching
Standard code/Nonstandard code
29 Nonstandard code
setting
Nonstandard code settings for STX, ETX, ESC,
ENQ, CAN, NULL, OFFLINE
30 Download Firmware download Download firmware from the host computer.
31 Reboot mode *5 (1) Start up in program download mode
(Available in normal operation mode only)
(2) Start up in normal operation mode
(Available in program download mode only)
No. Category Setting item Setting contents
