SATO CL408e/CL412e Service Manual
Section 9. Optional Accessories
1 Overview .......................................................................................................... 9-1
2 Label Cutter Kit Installation............................................................................ 9-2
3 Label Dispenser Kit Installation ..................................................................... 9-6
4 PCMCIA Memory Expansion Installation .................................................... 9-16
5 Flash Memory Expansion Installation ......................................................... 9-23
6 Real Time Clock Installation ......................................................................... 9-26
Section 10. Parts List
1 Overview ........................................................................................................ 10-1
2 Frame Assembly............................................................................................ 10-2
3 Print Head Assembly .................................................................................... 10-5
4 Ribbon Assembly .......................................................................................... 10-9
5 Base Cover Assembly................................................................................. 10-13
6 Main PCB Assembly.................................................................................... 10-20
7 Interface Options ......................................................................................... 10-21
8 PCMCIA Memory Option ............................................................................. 10-22
9 Cutter Assembly Option ............................................................................. 10-23
10 Dispenser Assembly Option .......................................................................10-25
Index .............................................................................................................................. Index -1
Table of Contents

SATO CL408e Specifications

General

Print Resolution	203 dpi
Print Speed	4 inches per second
Print Method	Thermal Transfer / Direct Thermal
Memory	2 MB Flash
Connectivity	RS-232C
Media Thickness	0.0025" - 0.01"
Supported Barcode Types	Code 39, Code 128
Operating Temperature	41°F to 104°F
Storage Temperature	140°F
Print Width	4.1"
Media Type	Roll or Fan-Fold
