Page 1-1
PN 9001078
Rev. A
SATO CL408e/CL412e Service Manual
Overview and Specifications
1.1 Overview
Section
The sections in this manual cover the following:
· Section 1. Overview and Specifications
· Section 2. Configuration
· Section 3. Interface Specifications
· Section 4. Electrical Checks and Adjustments
· Section 5. Mechanical Adjustments
· Section 6. Replacement Procedures
· Section 7. Factory Resets
· Section 8. Troubleshooting
· Section 9. Optional Accessories
· Section 10. Parts list
· Index
The SATO CL408e/CL412e Printers Service Manual provides information for
installing and maintaining CL408e/CL412e Thermal Transfer printers. Step-by-
step maintenance instructions are included in this manual with typical problems
and solutions. It is recommended that you become familiar with each section in
this manual before installing and maintaining the printer.
The major differences in the CL408e and the CL412e printers is the resolution of
the head. The CL408e with its 203 dpi head provides an economical labeling
solution for most applications. It can print labels up to 4.1 inches wide. The
CL412e provides a higher print resolution, 305 dpi to give laser-quality printing. It
is useful when higher resolution is needed for detailed graphic images.
The CL Series "e" printers use a subset of the standard SATO Command
Language. The CL408e/CL412e share the same command set, the only
differences are the allowable values representing the print positions on the label.
These values are specified in "dots" and will vary depending upon the resolution
of the printer and the amount of memory available for imaging the label. The
allowable range for each printer is specified in a table for those command codes.
