%a Rotate. Fixed Base Reference Point. Rotates printing in 90°
increments without changing the base reference point.
a = 0 Sets print to normal direction
1 Sets print to 90° CCW
2 Sets print to 180° rotated (upside down)
3 Sets print to 270° CCW (90° CW)
Page 5-
$a,b,c,d Vector font. Specifies printing of the unique SATO vector font.
a = A Helvetica Bold (proportional spacing)
B Helvetica Bold (fixed spacing)
b = Font width (50-999 dots*)
c = Font height (50-999 dots*)
d = Font variation (0-9) as follows:
0 Standard
1 Standard open (outlined)
2 Gray (mesh) pattern 1
3 Gray (mesh) pattern 2
4 Gray (mesh) pattern 3
5 Standard, shadow 1
6 Standard, shadow 2
7 Standard mirror image
8 Italic
9 Italic open (outlined)
Page 5-
$=(data) Data for Vector font. Page 5-
#Ea Print Darkness. Specifies a new print darkness setting. The lightest
setting is “1”. The darkenss levels that can be specified are:
Page 5-
CL408e CL412e CL608e CL612e
a = Print Darkness 1, 2, 3, 4, or 5 1, 2 or 3
Appendix A: Command Quick Reference
Page A-8 PN 9001074 Preliminary SATO CL Series “e” Printers
INSTRUCTION DESCRIPTION PAGE
