SATO CL6NX User Manual

Basic Specifications of the Barcode Check Function
628
Item Specification
(1) Media feed direction
(2) Cutter cover
(3) Cut position
(4) Print head
(5) Range in which white voids occur
Linerless mode (CL4NX only)
Barcodes printed within a range of 25 mm (0.98") from the trailing
end of the label cannot be read as it is blocked by the cutter cover.
(1) Media feed direction
(2) Cutter cover
(3) Cut position
(4) Print head
(5) Readable area (for the minimum media pitch)
(6) Unreadable area
(7) Minimum media pitch
Media
width
Same as the printer specifications.Usable Media
Sizes
Media
Pitch
The minimum size is different from the printer specifications.
Continuous mode
◦ 203 dpi: 20 to 2497 mm (0.79" to 98.30") (with liner: 23 to 2500 mm
(0.90" to 98.42"))
◦ 305 dpi: 20 to 1497 mm (0.79" to 58.94") (with liner: 23 to 1500 mm
(0.90" to 59.05"))

SATO CL6NX Specifications

General

Flash memory	2000 MB
Storage media	Flash
Internal memory	256 MB
Built-in barcodes	Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, Industrial 2/5, Interleaved 2/5, Matrix 2/5
Internal storage capacity	2 GB
Cables included	AC
Maximum roll diameter	220 mm
Maximum printing width	167.5 mm
Printing media thickness	0.08 - 0.268 µm
USB port	Yes
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0
Serial interface type	RS-232C
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Wi-Fi	No
Display type	LCD
Product color	Black
Display diagonal	3.5 \
Display resolution	320 x 240 pixels
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Type	POS printer
Print speed	10 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	203 x 203 DPI

Weight and Dimensions

Depth	457 mm
Width	338 mm
Height	321 mm
Weight	20000 g
