Parts Identification for the Operator Panel
(1) Power button
To power on the printer, press the power button until the LED lights up in blue.
To power off the printer, press the power button for more than two seconds.
(2) LED indicator
(3) Color LCD
(4) Soft buttons
The functions change depending on the screen. The functions of the buttons are indicated on the
bottom of the screen.
Example 1: In Offline mode
left soft button: ONLINE, right soft button: FEED
