26 SawStop 10” Professional Cabinet Saw
Get to Know Your Saw
The major components of your saw are identifi ed below. Make sure you can identify these components in order
to follow the instructions in this manual.
1. Table Top
2. Extension Wings
3. Blade Guard Assembly
4. Standard Table Insert
5. Elevation Handwheel
6. Tilt Handwheel
7. Tilt Angle Indicator
8. Tilt Angle Scale
9. Switch Box
10. Bypass Key
11. Thermal Overload Switch
12. Blade Wrenches (2)
13. Miter Gauge
14. Miter Gauge Slots
15. Accessory Tool Holder
16. Riving Knife
17. Side Access Panel
18. Motor Cover
19. Dust Port
20. Rear Access Panel
External Components
7
5
6
2
3
9
8
16
10
12
11
4
1
2
17
15
13
18
14
20
19
16
3
Fig. 32
Fig. 33
