SawStop PCS175 - Internal Assembly Parts List

No. Description Part No. Qty.
1 1.75 HP, 1 PH, 115/230V, 60Hz, TEFC Motor PCS-073 1
2 M12x1.75x65 Hex Head Bolt PCS-074 2
3 M5x5x30 Key PCS-075 1
4 Motor Pulley PCS-077 1
5 M6x1.0x8 Set Screw PCS-078 2
6 Front Trunnion Bracket PCS-079 1
7 M10x1.5x25 Hex Head Bolt PCS-080 4
8 M10 Lock Washer PCS-081 4
9 M10x25x3 Washer PCS-082 6
10 M10x1.5x30 Hex Head Bolt PCS-083 3
11 M10x1.5 Hex Jam Nut PCS-084 3
12 M8x20 Pin PCS-085 2
13 M8x1.25x16 Set Screw PCS-086 1
14 Front Trunnion PCS-087 1
15 Upper Torque Tube PCS-088 1
16 M6x1.0x20 Socket Cap Screw PCS-089 18
17 M6 Lock Washer PCS-090 27
18 Cable Clamp PCS-091 3
19 Rear Trunnion PCS-092 1
20 Rear Trunnion Bracket PCS-093 1
21 M8x1.0x20 Set Screw PCS-094 1
22 Lower Torque Tube PCS-095 1
23 M6x1.0x12 Socket Cap Screw PCS-096 3
24 Rubber Bumper PCS-097 1
25 M5x2.2x20 Button Head Phillips Screw PCS-098 8
26 M5 Lock Washer PCS-099 4
27 Dust Shroud (inner half) PCS-100 1
28 Dust Shroud (outer half) PCS-101 1
29 Dust Shroud Blast Shield PCS-102 1
30 Elevation Control Shaft Front Bushing PCS-103 1
31 Tilt Indicator PCS-104 1
32 M6x1.0x15 Button Head Socket Screw PCS-105 2
33 Tilt Handwheel Lock Knob PCS-106 1
34 Handwheel Handle PCS-107 2
35 Handwheel PCS-108 2
36 M6x1.0x8 Set Screw PCS-109 2
37 M5x5x25 Key PCS-110 2
38 Control Shaft Key PCS-111 2
39 Elevation Control Shaft PCS-245 1
SawStop 10” Professional Cabinet Saw 103
Internal Assembly Parts List
