SawStop PCS175 - Page 106

No. Description Part No. Qty.
40 Elevation Control Shaft Rear Bushing PCS-246 1
41 M4x4x20 Key PCS-114 1
42 Elevation Control Worm PCS-115 1
43 M8x23x2 Hardened Washer PCS-116 1
44 M8x1.25x16 Button Head Socket Screw PCS-117 1
45 Tilt Control Shaft PCS-118 1
46 M4x20 Spring Pin PCS-119 1
47 Tilt Control Worm PCS-120 1
48 M12x21x2 Washer PCS-121 1
49 Tilt Control Worm Adjustment Bracket PCS-122 1
50 Tilt Control Worm Adjustment Bracket Bushing PCS-123 1
51 M8x16x2 Washer PCS-124 2
52 Tilt Control Shaft Spacer PCS-125 1
53 Elevation Plate PCS-126 1
54 Primary Elevation Shaft PCS-127 1
55 Primary Elevation Shaft Bushing PCS-128 2
56 M8x1.25x40 Socket Cap Screw PCS-129 2
57 M8 Lock Washer PCS-130 7
58 M8x1.25x30 Socket Cap Screw PCS-131 3
59 Gas Spring Mounting Bracket PCS-132 1
60 Gas Spring PCS-256 1
61 Elevation Threaded Rod PCS-134 1
62 M8x1.25x25 Hex Head Bolt PCS-135 2
63 M6x1.0x16 Set Screw PCS-136 2
64 Secondary Elevation Shaft PCS-137 1
65 Secondary Elevation Shaft Bushing PCS-138 1
66 M6x1.0x55 Socket Cap Screw PCS-139 2
67 Secondary Elevation Shaft Standoff PCS-140 2
68 M6x1.0 Lock Nut PCS-141 2
69 M13 External Retaining Ring PCS-142 2
70 Elevation Worm Gear PCS-143 1
71 M4x4x15 Key PCS-144 2
72 Elevation Gear Shaft Bushing PCS-145 2
73 Elevation Gear Shaft Mounting Bracket PCS-146 2
74 Elevation Gear Shaft PCS-147 1
75 M6x15x1.5 Washer PCS-148 6
76 Elevation Pinion Gear PCS-149 1
77 Spreader Mounting Plate PCS-150 1
78 M10x1.5x25 Socket Cap Screw PCS-151 2
79 M8x1.0 Hex Nut PCS-152 1
80 Spreader Positioning Plate PCS-153 1
104 SawStop 10” Professional Cabinet Saw
Internal Assembly Parts List
