No. Description Part No. Qty.
81 M3x0.5x6 Set Screw PCS-154 1
82 Clamp Spring PCS-155 1
83 Clamping Plate PCS-156 1
84 Clamping Plate Cam Bushing PCS-157 1
85 Clamp Handle PCS-158 1
86 M8x1.0x40 Hex Head Bolt PCS-159 1
87 M4x0.7x6 Set Screw PCS-160 1
88 Riving Knife PCS-161 1
89 Elevation Handwheel Lock Knob PCS-162 1
90 Tilt Control Shaft Collar PCS-163 1
91 M4x0.7x12 Socket Cap Screw PCS-164 1
92 M8 Polyurethane O-Ring PCS-165 1
93 Dust Shroud Clip PCS-166 2
94 Dust Shroud Mounting Bracket PCS-167 1
95 M5.2x10 Spring Pin PCS-168 1
96 M6x1.0x30 Socket Cap Screw PCS-169 4
97 M6x22 Pin PCS-242 2
98 Elevation Control Shaft Collar PCS-247 1
99 M5x0.8x16 Socket Cap Screw PCS-248 1
100 M20x32x2 Washer PCS-249 1
101 M6x1.0x10 Custom Set Screw PCS-250 1
102 M6x1.0x25 Socket Cap Screw PCS-261 2
SawStop 10” Professional Cabinet Saw 105
Internal Assembly Parts List
