Currency Discrimination Fitness Sorter SB - 2000 Service Manual
62
WARNING
FOR PROPER SHADING
REFER TO THE SVC
MANUAL
PRESS ESC TO CANCEL
PRESS ENTER TO GO
CAP SHADING
STEP2..
PLACE 1 SHADING SHEET
ON CAP SENSOR
THEN PRESS START
Press ‘START’ key
1. Open rear cover and wipe the metallic
roller with soft cloth.
2. Place the CAP shading sheet over metallic
rollers array as shown on the following
picture.
3. Close the rear cover.
Press ‘START’ key
