18
transmission; then one needs to enter the waiting time in milliseconds (tiME), in
4 digits, between a transmission and another.
The TIME OUT of a printout is a minute, in other words, after a minute that the printout is
blocked, it is cancelled.
NOTE: the parameter is not displayed if “Pr- no” has been selected in the “PrModE”
step.
(!) noCtS
PrConF CONFIGURATION OF THE PRINTOUTS
See the “Print Programming” section for the description of all the menu’s parameters.
NOTE: the parameter and all its submenus are not displayed if “Prno” has been
selected in the “PWr.Prn” step or “Pr- no” in the “PrModE” step.
CoM.PC TRANSMISSION bidirectional
(RS232 or 485 depend of the PC SEL choice)
PCModE TRANSMISSION SERIAL OUTPUT
ondE transmission on external command PC (given from PC or PLC, for example)
rEPE.4 transmission to 4 digit remote display.
rEPE.6 transmission to 6 digit remote display IPE50.
Prin.St. transmission of standard string when the ENTER key is pressed.
Prin.EH transmission of extended string when the ENTER key is pressed.
NOTE: if the “TOTALIZER” mode (horizontal or vertical) is active, the
transmission through the key is carried out by pressing the MODE key.
485 transmission with 485 protocol, by confirming with ENTER/PRINT, one is
required to enter the machine code (the message “Ad485 ou Addr” appears for
an instant): enter a value between 0 and 98.
Modbus protocol MODBUS
Profi b protocol PROFIBUS (option)
ALL.Std continuous transmission with standard string.
ALL.EHt continuous transmission with extended string.
ALL.MAX quick continuous transmission
StAb.St transmission with each weigh with standard string.
StAb.EH transmission with each weigh with extended string.
For the transmission modes and protocol specifications, see the “SERIAL PORTS
TRANSMISSION MODES” and “TRANSMISSION PROTOCOLS” sections.
(!) OndE
bAud SET BAUD RATE
By pressing the ENTER key one accesses the selection of the data transmission speed
(measured in Baud = bit/second). The possible values are: 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200.
(!) 9600
bit SET PARITY, WORD, STOP BIT
By pressing the ENTER key, selection of the values: n-8-1, n-8-2, n-7-2, E-7-1, E-7-2.
(!) n-8-1
