Ctrl Command set_softstart_level
Function sets the softstart values.
Parameters All parameters must be unsigned 16-bit values.
Parameter Allowed Values Description
index 0...n index number of the softstart table value
level 0 … 1023
2…2
16
-1
for softstart mode = 1, 2, 11 and 12. Value 0 corresponds to 0 V; value
1023 corresponds to 2.56 V (for jumper X3 position 1-2) or 10 V (for
jumper X3 position 2-3).
for softstart mode = 3 and 13 (see set_softstart_mode). 1 bit
corresponds to 1 µs or 1/8 µs depending on the time base which can be
specified with the command set_laser_timing (also see page 33).
Integration Pascal: procedure set_softstart_level (index, level: word);
C: void set_softstart_level (unsigned short index, unsigned short
level);
Basic: sub set_softstart_level (ByVal index%, ByVal level%)
Comments • The softstart mode is enabled by the command set_softstart_mode (also see section
"Softstart Mode" on page 35).
•The set_softstart_mode command must be called before first-time use of the
set_softstart_level command.
• Please be sure to set as many softstart values as you defined by set_softstart_mode.
References • set_softstart_mode
