RTC
®
4 PC Interface Board
Rev. 1.3 e
10 Commands And Functions
120
innovators for industry
List Command timed_jump_abs
Function jump to the specified position in the image field using the specified duration
Parameters
xval,
yval
absolute coordinates of the vector end point in bits as signed 16-bit values.
time
duration of the complete jump vector in microseconds
Allowed range: [10 … 655350] (64-bit IEEE floating point value)
Integration Pascal:
procedure timed_jump_abs(xval, yval: smallint; time: double);
C:
void timed_jump_abs(short xval, short yval, double time);
Basic:
sub timed_jump_abs(ByVal xval%, ByVal yval%, ByVal time#)
Comments • The parameter
time
will be rounded down to a multiple of 10 µs (within the allowed
range).
•A timed jump (mark) command will not be executed with the normal jump speed
(marking speed). Instead, the speed (i.e. the number of microsteps) will be adjusted
so that the vector lasts exactly as long as specified.
Also see chapter 5.8 "Timed Jump And Mark Commands", page 50.
• Note: After a timed jump, a jump delay is inserted, just like after a normal jump.
That means the total time for the jump is the specified time plus the jump delay.
•Subsequent jump_abs / jump_rel commands (not timed) will be executed with the
normal jump speed. (See set_jump_speed, page 107.)
References set_scanner_delays, timed_jump_rel
List Command timed_jump_rel
Function jump to the specified position in the image field using the specified duration
Parameters
dx, dy
relative coordinates of the vector end point in bits as signed 16-bit values.
time
duration of the complete jump vector in microseconds
Allowed range: [10 … 655350] (64-bit IEEE floating point value)
Integration Pascal:
procedure timed_jump_rel(dx, dy: smallint; time: double);
C:
void timed_jump_rel(short dx, short dy, double time);
Basic:
sub timed_jump_rel(ByVal dx%, ByVal dy%, ByVal time#)
Comments • The coordinates are relative to the current position.
• The maximum value for the absolute coordinates is ±32767 bits.
• See timed_jump_abs.
References set_scanner_delays, timed_jump_abs
