Scanlab RTC 4 - Page 122

RTC
®
4 PC Interface Board
Rev. 1.3 e
10 Commands And Functions
122
innovators for industry
Ctrl Command write_8bit_port
Function writes an 8-bit value to the digital output port on the LASER EXTENSION connector
Parameter
value output value for the digital output port as unsigned 16-bit value.
Allowed range: [0 … 255]
Integration Pascal: procedure write_8bit_port(value: word);
C: void write_8bit_port(unsigned short value);
Basic: sub write_8bit_port(ByVal value%)
Comments • Please refer to chapter "8-Bit Digital Output Port", page 53, and to the section "Digital
Output Port (Laser Extension Connector)", page 60.
• The upper 8 bits of the specified value are ignored.
References write_8bit_port_list
List Command write_8bit_port_list
Function same as write_8bit_port (see above), but a list command
Integration Pascal:
procedure write_8bit_port_list(value: word);
C: void write_8bit_port_list(unsigned short value);
Basic: sub write_8bit_port_list(ByVal value%)
Ctrl Command write_da_1
Function see write_da_x
Integration Pascal:
procedure write_da_1(value: word);
C: void write_da_1(unsigned short value);
Basic: sub write_da_1(ByVal value%)
List Command write_da_1_list
Function see write_da_x_list
Integration Pascal:
procedure write_da_1_list(value: word);
C: void write_da_1_list(unsigned short value);
Basic: sub write_da_1_list(ByVal value%)
Ctrl Command write_da_2
Function see write_da_x
Integration Pascal:
procedure write_da_2(value: word);
C: void write_da_2(unsigned short value);
Basic: sub write_da_2(ByVal value%)
