13.2 Technical specifications
HEATER400-1600
Type HEATER400-SMART HEATER600-SMART HEATER800-SMART HEATER1600-SMART
Touchscreen Yes
Frequency 50-60Hz
Temperature measurement Double, ΔT measurement, Log functionality
Operating modes Time, Temperature, Temperature or time, Temperature & speed
Weight kg 150 170 250 720
Max. temperature 240°C / 464°F
Max. bearing weight kg 400 600 800 1600
Max. OD Ø mm A 850 1050 1150 1700
Space between poles mm B 320 400 430 710
Pole height mm C 305 315 515 780
Pole surface mm D 80x100 90x110 180x180 230x230
Dimensions mm (LxWxH) 1214x560x990 1344x560x990
1080x650x955
1080x650x1025*
1520x750x1415
1520x750x1485*
*Height with optional wheels
HEATER400 - 600 HEATER800 - 1600
