13. Technical specifications
13.1 Technical specifications
HEATER50-200
Type HEATER50-SMART HEATER100-SMART HEATER150-SMART HEATER200-SMART
Touchscreen Yes
Frequency 50-60Hz
Temperature measurement Double, ΔT measurement, Log functionality
Operating modes Time, Temperature, Temperature or time, Temperature & speed
Weight kg 21 31 52 56
Max. temperature 240°C / 464°F
Max. bearing weight kg 50 100 150 200
Max. OD Ø mm A 400 500 600 600
Space between poles mm B 120 180 210 210
Pole height mm C 130 185 205 205
Pole surface mm D 40x50 50x50 70x80 70x80
Dimensions mm (LxWxH)
600x226x272 702x256x392 788x315x456 788x315x456
HEATER50 - 150
