Schaeffler SMART Series - Ledges (Yokes)

60 Schaeer Technologies
HEATER50-SMART
Name
Min. bore
diam. (mm)
Size
mm
Weight
kg
Swivel
arm
Scope of
delivery
Optional
HEATER50.YOKE-10 10 7x7x200 0,08 No
✓
HEATER50.YOKE-15 15
10x10x200
0,15 No
✓
HEATER50.YOKE-20 20 14x14x200 0,32 No
✓
HEATER50.YOKE-30 30 20x20x200 0,61 No
✓
HEATER50.YOKE-60 60 40x40x200 2,42 No
✓
HEATER50.YOKE-65 65 40x50x200 3,02 No
✓
HEATER100-SMART
Name
Min. bore
diam. (mm)
Size
mm
Weight
kg
Swivel
arm
Scope of
delivery
Optional
HEATER100.YOKE-15 15 10x10x280 0,21 Yes
✓
HEATER100.YOKE-20 20 14x14x280 0,40 Yes
✓
HEATER100.YOKE-30 30 20x20x280 0,84 Yes
✓
HEATER100.YOKE-45 45 30x30x280 2,40 Yes
✓
HEATER100.YOKE-60 60 40x40x280 3,87 Yes
✓
HEATER100.YOKE- 68 72 50x50x280 5,78 Yes
✓
HEATER100.YOKE-85 85 60x60x280 8,09 Yes
✓
HEATER150-SMART / HEATER200-SMART
Name
Min. bore
diam. (mm)
Size
mm
Weight
kg
Swivel
arm
Scope of
delivery
Optional
HEATER200.YOKE-15 15 10x10x350 0,27 Yes
✓
HEATER200.YOKE-20 20 14x14x350 0,51 Yes
✓
HEATER200.YOKE-30 30 20x20x350 1,06 Yes
✓
HEATER200.YOKE-45 45 30x30x350 3,67 Yes
✓
HEATER200.YOKE-60 60 40x40x350 5,51 Yes
✓
HEATER200.YOKE-68 68 50x50x350 7,79 Yes
✓
HEATER200.YOKE-85 85 60x60x350 10,69 Yes
✓
HEATER200.YOKE-100 100 70x70x350 14,01 Yes
✓
HEATER200.YOKE-110 110 70x80x350 15,90 Yes
✓
13.4 Ledges (Yokes)
