6. Technical data
Technical data
Number of knives 2 pieces
Cutter block rpm 8500 1/min
Dimensions 970 x 490 x 485 mm
Weight 27 kg
Technical data – Surfacing
Max planing width 254 mm
Max chip removal 2 mm
Ripping fence l x h 635 x 127 mm
Ripping fence tilting
angle
90°–135°
Surfacing table size 920 x 264 mm
Technical data – Thicknessing
Max planing width 254 mm
Max planing thickness 120 mm
Max chip removal 2 mm
Thicknessing table size 380 x 254 mm
Drive
Motor 230V / 50 Hz
Consumption power P1 1500 W
Subject to technical changes!
Sound
Sound values were measured in accordance with EN
61029.
Sound pressure level L
pA
89 dB (A)
pA
3 dB
Sound power level L
WA
102 dB (A)
WA
3 dB
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a
minimum!
•
order.
•
•
• Do not overload the appliance.
•
•
7. Before starting the equipment
Before each use, check the following:
•
• Locked disconnected protective equipment
(Fig. 1a - pos. 3)
checking that the machine cannot be turned on
whenever the protective equipment is open
• Brake
Switch on the machine at the start of work and al-
low the machine to reach speed. Now switch the
standstill within 10 seconds. Otherwise, there is a
defect.
• Anti-kick claws (Fig. 4 - pos. 25)
example, that the contact surface has not been
(25) fall back without hindrance due to their own
weight;
• Planing blades (Fig. 13 - pos. 24)
-
The machine may only be used if all these condi-
tions are satised.
Use pusher wood or sticks which are in perfect con-
dition for machining short workpieces.
Connect the machine to a dust and chip extractor.
Check that the stop is secure before starting the ma-
chining work.
times. Stand to the side of the machine.
a safe distance from the cutting block and from the
point at which the chips are discharged.
Do not start the planing work until the cutting block
has reached the required speed.
wood which has lots of knots or knot holes.
Secure long workpieces to prevent them tipping over
at the end of the planing process. Use roller stands,
for example, or similar devices for this purpose.
