15. Trouble shooting
Problem Possible Cause Remedy
Machine cannot be
switched on.

Carbon brush worn.
Chip extractor not mounted


Machine does not work

Power cut
Motor or switch defective
Check microswitch
Check fuse, check overload switch on machine.

Fit the chip extractor hood so that the microswitch is
pressed.
Check fuses.
Due to the integrated lowvoltage protection, the ma-

the voltage, the machine must be switched on again.
Machine stops during
planing.
Planing blade blunt/worn
Overload switch has tripped
Check microswitch
Too much chip removal
Too fast feed
Replace or sharpen blade
Switch on the motor again once it has cooled
Fit the chip extractor hood or bench lock so that the
microswitch is pressed.
Reduce chip removal.
Reduce infeed speed.
Workpiece jams during
thicknessing
Cutting depth too great Reduce cutting depth and machine the workpiece in
several passes
Speed decreases when
planing
Too much chip removal
Too fast feed
Blunt knives.
Reduce chip removal.
Reduce infeed speed.
Replace knives.


Planing blade blunt/worn

Uneven feed
Replace or sharpen blade
Remove chips
Feed the workpiece with constant pressure and at
reduced speed
Machined surface too
rough
Workpiece contains too much
moisture

Machined surface
cracked
Workpiece was machined against
the grain
Too much material planed at one
pass
Machine the workpiece from the opposite direction
Machine the workpiece in several passes
Workpiece speed too
low during thicknessing
Workpiece was machined against
the grain
Too much material planed at one
pass

wax
Repair transport rollers
Set the lever for the thicknessing setting to the top
position
When thicknessing,
chip ejection obstructed
(without dust extractor).
Too much chip removal
Blunt knives.
Wood too humid.
Reduce chip removal.
Replace knives

When surface planing,
chip ejection obstructed
(without dust extractor)
Too much chip removal
Too fast feed
Blunt knives.
Wood too humid.
Reduce chip removal.
Reduce infeed speed.
Replace knives.

With surface planing
and thicknessing, chip
ejection obstructed
(with dust extractor).
Suction performance too weak. 
suction connection of at least 20 m/s.

Scheppach HMS1070 Specifications

General

Idle speed	8500 RPM
Product color	Black, Blue
AC input voltage	230 V
AC input frequency	50 Hz
Soleplate material	Aluminum
Dust extraction port	Yes
Planning width (max)	252 mm
Input power	1500 W
Power source	AC
Number of blades	2
Planing depth (max)	120 mm

Weight and Dimensions

Depth	1020 mm
Width	520 mm
Height	400 mm
Weight	30900 g
