Control System and Electric System (PX 105)FIT--Wa 1159850Dec./06 en
1 Technical Description
System overview
The supply ships ”PX 105” are each fitted with two
SCHOTTEL Combi Drives (SCD 2020 Twin).
Each system includes:
D SCD 2020 Twin
D Lubrication oil maintenance unit
D Oil compensating reservoir
D Condensation water pump
D Energy supply switch cabinet
D Controls switch cabinet
D Brake resistance
D Board of main control stand
D Board of engine room
D PS--board of chair control stand
D STB--board of chair control stand
D Additional displays, bridge deck
D Additional displays, main control stand
D Tiller (for port--side and starboard system in
common)
Given that the subassemblies of both systems are
arranged mirror--inverted, in the following only the
starboard system is detailed.
The system is controlled on the bridge deck whether
from the board of the main control stand (1/11) or from
one chair control s tand board (1/5 or 6).
Additionally to the displays in the main control stand
board (1/11) above the control desk there are additional
displays (1/9) for the thrust direction and speed of the
system.
Additional displays (1/1) are also in the centre of the
bridge deck at the sight of the master mariner.
On the chair control stand, there is each one control
lever PS (1/7) and one control lever STB (1/8).
Different from the above mentioned operating
elements, the tiller (1/10) arranged close to the main
boards, is present only once.
The system can also be controlled from the engine
room board (1/12).
Besides the components for the controls of the system,
the switch cabinets also includes the components for
the controls of the lubrication oil maintenance unit
(1/17) and for the condensation water pump (1/16).
Legend for Figure 1
1 Additional displays, bridge deck
2 PS displays on chair control stand
3 Chair control stand
4 STB displays on chair control s tand
5 PS--board of chair control stand
6 STB--board of chair control stand
7 PS control lever of chair control stand
8 STB control lever of chair control stand
9 Additional displays, main control stand
10 Tiller
11 Board of main control stand
12 Board of engine room
13 Energy supply switch cabinet
14 Controls switch cabinet
15 Oil compensating reservoir
16 Condensation water pump
17 Lubrication oil maintenance unit
18 Brake resistance
19 SCD 2020 Twin
